Product
Reaction wash column
Material
Full GRP (Derakane 470)
Medium
Oil and kerosene
Dimensions
70 m³, Ø 3000 mm, L = 10 m
Temperature
80°C, short temp. 120°C
Pressure
Atm.
Product
Fuel tank
Material
Full GRP (Derakane 411)
Medium
Fuel
Dimensions
50 m³
Temperature
40°C, design 80°C
Pressure
Atm.
Product
Storage Tank
Dimensions | Volume
Ø 2500 x 5280 mm | 20m³
Temperature
40°C
Pressure
-0.05 / +1.5 bar
Medium
96% mixed acid (84% H2SO4, HCL and others acids)
Dimensions
Ø 3600 x 6485 mm
Temperature
80°C
Pressure
Pressureless
Medium
96% H2SO4 + organic solvents
Dimensions
Ø 5000 x 11000 mm
Temperature
-20°C / +40°C
Pressure
-0.02 / +0.02 bar
Medium
96% H2SO4 + organic solvents
Dimensions
Ø 5000 x 11000 mm
Temperature
-16°C / +50°C
Pressure
Atm.
Dimensions
ø 1800 mm
Volume
5000 l
Height
3000 mm
Product
Storage Tank
Dimensions
Ø 2500 x 5100 mm
Temperature
-5°C / +40°C
Pressure
-0.05 / +1.5 bar
Material
failed liner: 1.5 mm PFA,
new liner: 2.3mm PFA-HP
Medium
ultra-pure HNO3
Relining date
1991
